Stainless Steel Low Profile Floor Scale

The Stainless Steel Low Profile Floor Scale features a corrosion-resistant, hygienic design ideal for food, chemical, and pharmaceutical industries. With an ultra-low platform height, it allows easy loading via pallet jacks or carts. Durable, accurate, and washdown-ready, it's perfect for cleanroom and wet environments.
  • SS-LF

  • Massive weighing

Size:
Capacity:
Availability:
Quantity:

Product Description

Stainless Steel Low Profile Floor Scale


Stainless Steel Low Profile Floor Scale

Stainless Steel Low Profile Floor Scale


Key Features:

● Full 304/316 Stainless Steel Construction

Crafted from high-grade 304 or 316 stainless steel, the scale offers excellent resistance to corrosion, chemicals, and moisture. Ideal for food processing, pharmaceutical, and chemical industries requiring strict hygiene compliance with GMP and HACCP standards.

● Ultra-Low Platform Height

With a platform height as low as 40mm–60mm, it reduces loading angles and allows effortless access for pallet jacks, carts, or trolleys—no floor pit required. Perfect for facilities with space constraints or temporary installations.

● IP67/IP68 Rated Load Cells

Equipped with stainless steel load cells that meet IP67 or IP68 standards, ensuring accurate, stable weighing performance in wet, washdown, or industrial environments. Protected against dust, water, and heavy usage.

● Slip-Resistant Surface Options

The scale deck features either a diamond tread plate or brushed finish to enhance traction and prevent slipping during loading or unloading, improving safety in damp or fast-paced work areas.

● Hygienic & Easy to Clean Design

All components are designed with smooth surfaces and sealed structures to allow quick and thorough cleaning, supporting hygienic operations in cleanrooms or food-grade areas.



Applications:

● Food Processing and Packaging:

Ideal for weighing ingredients, bulk food products, or packaged goods in meat, seafood, dairy, and bakery environments. The washdown-ready design ensures compliance with HACCP and hygiene regulations.

● Pharmaceutical and Cleanroom Operations:

Perfect for cleanroom environments where contamination control is critical. Suitable for weighing active ingredients, filled containers, or medical supplies during production or quality checks.

● Chemical and Pharmaceutical Industries:

Handles corrosive or hazardous materials with ease. The stainless steel construction resists chemical exposure, and the IP68 load cells ensure accuracy in challenging conditions.

● Wet and Washdown Areas:

Designed for environments where frequent cleaning is required—such as beverage plants, sanitation zones, or fish markets. Smooth surfaces and sealed electronics allow for safe hose-down procedures.


Why choose our Stainless Steel Low Profile Floor Scale?

● Hygienic and Corrosion-Resistant Design:

Made from premium 304 or 316 stainless steel, our scale is built for sanitary environments and resists corrosion from moisture, chemicals, and daily washdowns—ideal for food, pharma, and chemical industries.

● Ultra-Low Profile for Easy Access:

With a platform height as low as 40mm, it allows smooth loading of pallet jacks and carts without the need for floor pits, reducing labor and improving workflow efficiency.

● Built for Harsh Environments:

Equipped with IP67/IP68-rated stainless steel load cells, the scale maintains high accuracy and performance in wet, dusty, or aggressive industrial settings.

● Easy to Clean and Maintain:

Smooth welded surfaces and sealed components support fast, thorough cleaning—ensuring hygiene compliance and minimizing downtime.



Stainless Steel Low Profile Floor Scale

Stainless Steel Low Profile Floor Scale

Stainless Steel Low Profile Floor Scale


Specifications

Item

Specification

Model

SS-LF Series

Platform Size (L×W)

1000×1000mm / 1200×1200mm/1500x1500mm / Customized

Capacity

500kg / 1t / 2t / 3t/5t/10t

Accuracy Class

OIML III

Platform Material

4mm Thickness carbon steel

Structure

Indicator & Scale Platform Separated

Indicator Housing

Stainless Steel or ABS Optional

Display

LED or LCD with backlight

Load Cell

IP67 Stainless Steel Load Cells

Cable

Double Shielded Cable,5 meters standard

Power Supply

AC 110~220V / Built-in Rechargeable Battery

Function

Tare, Zero, Accumulate, Unit Conversion, Counting

Optional Features

Ramp, Printer, RS232/RS485, Bluetooth/Wi-Fi, Barcode Scanner

Usage

Ideal for food, chemical, pharmaceutical, and cleanroom applications

Installation

Simple installation, movable or pit-free setup


Video

FAQs


FAQs of Low Profile Floor Scale


Q1: What industries is the Stainless Steel Low Profile Floor Scale suitable for?

The scale is ideal for food processing, pharmaceutical, chemical, and cleanroom applications where hygiene, corrosion resistance, and washdown capability are critical.


Q2: Is the scale safe for use in wet or washdown environments?

Yes. The scale features full stainless steel construction and is equipped with IP67 or IP68-rated load cells and sealed junction boxes, making it fully washdown-ready and resistant to water, chemicals, and moisture.


Q3: What sizes and capacities are available?


Standard platform sizes include 1000×1000mm, 1200×1200mm, and 1500×1500mm, with capacities from 500kg up to 5 tons. Custom sizes and configurations are also available to meet specific operational needs.


Q4: Can I use this scale with pallet jacks or carts?


Absolutely. Its ultra-low design allows for easy access by pallet jacks and trolleys. Optional stainless steel ramps provide smooth drive-on and drive-off operation without requiring a floor pit.


Q5: What weighing functions and connectivity options are supported?


The scale works with advanced digital indicators offering tare, zero, unit conversion, accumulation, and counting. Optional connectivity includes RS232/RS485, Bluetooth, Wi-Fi, and printer integration for seamless data transfer.
