Electric Pallet Jack with Scale

Electric Pallet Jack with Scale

Key Features：

● Integrated Electric Drive and Weighing System

Combines powered pallet transport with high-precision weighing. Operators can move and weigh loads simultaneously, improving productivity and reducing manual labor.

● High-Accuracy Digital Scale

Equipped with advanced load cells and a digital indicator, the scale provides fast and accurate weight readings. Functions like tare, zero, hold, and unit conversion are easily accessible.

● Effortless Electric Operation

Features electric drive and lifting mechanisms, minimizing physical strain on operators. Ideal for long-distance transport or high-volume material handling in warehouses and logistics centers.

● Durable and Heavy-Duty Construction

Built with industrial-grade steel and a reinforced frame, it supports high-capacity loads and ensures long-term reliability even in tough environments.

● User-Friendly Control Panel

The intuitive control interface allows for easy operation of both lifting and weighing functions. Clear weight display, simple button layout, and responsive controls enhance user experience.

● Safety and Stability Features

Includes braking systems, anti-roll-back protection, and emergency stop functionality. These features ensure safe use on ramps, inclines, and in crowded workspaces.

Applications：

● Warehousing and Distribution Centers：

Ideal for efficiently moving and weighing pallets during order fulfillment, shipping, and receiving. It streamlines operations by reducing the need for separate weighing stations.

● Manufacturing and Assembly Lines：

Used to transport raw materials or finished goods between production stages while simultaneously capturing weight data for process control and quality assurance.

● Freight and Logistics Operations：

Enables precise weight verification of outbound shipments for billing, load planning, and compliance with transportation regulations, all while reducing handling time.

● Food and Beverage Industry：

Electric models with stainless steel or waterproof options are suitable for hygienic environments, allowing for clean, efficient weighing and transport of packaged goods.

● Cold Storage and Pharmaceutical Facilities：

Performs well in temperature-sensitive or regulated environments where fast, safe, and accurate movement and weighing of products are critical for traceability and safety.

why choose our Electric Pallet Jack with Scale ？

● Boosted Efficiency with Dual Functionality：

Our Electric Pallet Jack with Scale integrates powered transport and precision weighing in one device. It allows operators to move and weigh pallets simultaneously, reducing handling steps and significantly improving operational speed.

● Ergonomic and User-Friendly Design：

With electric drive and lift functions, ergonomic controls, and a clear digital display, the unit minimizes operator fatigue and simplifies daily tasks. Ideal for long shifts and high-frequency operations in busy industrial settings.

● Industrial-Grade Durability and Safety：

Constructed with a reinforced steel chassis and equipped with safety features like emergency stop and brake systems, our pallet jack is built to last in demanding environments while ensuring operator and load safety.

Item	Specifications
Capacity	500kg / 1000kg / 2000kg / 2500kg (optional)
Accuracy Class	Class III (OIML R76 compliant)
Division (d)	0.5kg / 1kg (based on model)
Display Type	LED or LCD with backlight
Power Supply	Rechargeable battery / DC adapter (typically DC 6V or 12V)
Charging Time	6–8 hours
Operating Time	40–60 hours (fully charged, depending on usage)
Material	Carbon steel with powder coating / Stainless steel (optional)
Fork Size	Width: 550mm / 685mm; Length: 1150mm
Wheel Material	Polyurethane / Nylon
Communication Port	RS232 / Bluetooth / Wi-Fi / USB (optional)
Printer Option	External thermal printer (optional)
Working Environment	Temperature: -10℃ to +40℃; Humidity: ≤90% RH
Protection Level	IP65 (depends on configuration)

FAQs for Electric Pallet Jack with Scale

1. Q: What is an Electric Pallet Jack with Scale and how does it benefit my operation?

• A: An Electric Pallet Jack with Scale is a powered pallet truck integrated with a digital weighing system. It lets you lift, transport, and weigh palletized goods in one seamless step—improving workflow efficiency, reducing handling time, and removing the need for a separate floor scale.

2. Q: How accurate is the built-in scale on an Electric Pallet Jack?

• A:Our Electric Pallet Jack with Scale uses high-precision load cells, typically offering an accuracy of ±0.1% of the applied load. This makes it ideal for shipping verification, inventory management, and production line weight checks.

3. Q: Can the Electric Pallet Jack with Scale be used in food or pharmaceutical environments?

• A: Yes. We offer models with stainless steel construction and waterproof components designed for hygienic or washdown environments, making them suitable for industries that require high cleanliness standards like food processing or pharmaceuticals.

4. Q: How is the unit powered and how long does the battery last?

• A: The pallet jack is powered by a rechargeable battery system that supports both the electric drive and the weighing scale. Depending on usage, a full charge can last up to 6–8 hours of continuous operation. The indicator may have its own internal battery or share power with the main system..

5. Q: Is the scale indicator easy to use, and what functions does it offer?

• A: Absolutely. The digital indicator features a clear LCD screen and intuitive controls, offering functions such as tare, zero, accumulation, and gross/net weight display. Optional upgrades include printers, Bluetooth/Wi-Fi for data transmission, and legal-for-trade certification for commercial transactions.
